KCK17絲錐牌號是加工什么材料的
| 牌號名稱 |
KCK17 |
| 牌號詳情描述 |
采用 PVD AlCrN 復合涂層的細晶粒硬質合金材質。特有涂層材料。在鑄鐵材料攻絲應用中具有良好的耐磨性。良好的高溫硬度性能確保非常長的使用壽命，攻絲速度比 HSS-E-PM 絲錐提高 4 倍。 |
| ISO應用范圍1 | K17 |
| ISO應用范圍2 | |
| 基體類型 | 硬質合金 |
| 牌號涂層 | PVD AlCrN 復合涂層 |
| 牌號顏色 | 黑色 |
應用于以下硬質合金絲錐產品系列:
T340M050X080R6HX KCK17 M5X0.8 6HX 3F STFL PLUG CARB
T340M060X100R6HX KCK17 M6X1 6HX 4F STFL PLUG CARB
T340M080X125R6HX KCK17 M8X1.25 6HX 4F STFL PLUG CARB
T340M100X150R6HX KCK17 M10X1.5 6HX 4F STFL PLG CARB
T340M120X175R6HX KCK17 M12X1.75 6HX 4F STFL PLG CARB
T340M140X200R6HX KCK17 M14X2 6HX 4F STFL PLG CARB
T340M160X200R6HX KCK17 M16X2 6HX 4F STFL PLG CARB
T340MF100X100R6HX KCK17 M10X1 6HX 4F STFL PLUG CARB
T340MF120X150R6HX KCK17 M12X1.5 6HX 4F STFL PLUG CARB
T340MF140X150R6HX KCK17 M14X1.5 6HX 4F STFL PLUG CARB
T340NC#10-24R3BX KCK17 NO. 10-24 3BX 3F STFL PLUG CARB
T340NC#8-32R3BX KCK17 NO. 8-32 3BX 3F STFL PLUG CARB
T340NC02500-20R3BX KCK17 1/4-20 3BX 4F STFL PLUG CARB
T340NC03125-18R3BX KCK17 5/16-18 3BX 4F STFL PLUG CARB
T340NC03750-16R3BX KCK17 3/8-16 3BX 4F STFL PLG CARB
T340NC05000-13R3BX KCK17 1/2-13 3BX 4F STFL PLG CARB
T340NF#10-32R3BX KCK17 NO. 10-32 3BX 3F STFL PLUG CARB
T340NF03750-24R3BX KCK17 3/8-24 3BX 4F STFL PLG CARB
T351M040X070R6HX KCK17 M4X0.7 6HX 3F STFL BOTT CARB
T351M050X080R6HX KCK17 M5X0.8 6HX 3F STFL BOTT CARB
T351M060X100R6HX KCK17 M6X1 6HX 4F STFL BOTT CH CARB
T351M060X100R6HX-D1 KCK17 M6X1 6HX STFL BOTT E 371 CH CARBIDE
T351M070X100R6HX-D1 KCK17 M7X1 6HX STFL BOTT E 371 CH CARBIDE
T351M080X125R6HX KCK17 M8X1.25 6HX 4F STFL BOTT CH CARB
T351M080X125R6HX-D1 KCK17 M8X1.25 6HX STFL BOTT E 371 CH CARBIDE
T351M090X125R6HX-D1 KCK17 M9X1.25 6HX STFL BOTT E 371 CH CARBIDE
T351M100X150R6HX KCK17 M10X1.5 6HX 4F STFL BOTT CH CARB
T351M100X150R6HX-D1 KCK17 M10X1.5 6HX STFL BOTT E 371 CH CARBIDE
T351M120X175R6HX KCK17 M12X1.75 6HX 4F STFL BOTT CH CARB
T351M120X175R6HX-D6 KCK17 M12X1.75 6HX STFL BOTT E 376 CH CARBIDE
T351M140X200R6HX KCK17 M14X2 6HX 4F STFL BOTT CH CARB
T351M160X200R6HX KCK17 M16X2 6HX 4F STFL BOTT CH CARB
T351M200X250R6HX KCK17 M20X2.5 6HX 5F STFL BOTT CH CARB
T351MF100X100R6HX KCK17 M10X1 6HX 4F STFL BOTT CH CARB
T351MF100X100R6HX-D4 KCK17 M10X1 6HX STFL BOTT E 374 CH CARBIDE
T351MF100X125R6HX-D4 KCK17 M10X1.25 6HX STFL BOTT E 374 CH CARBIDE
T351MF120X125R6HX-D4 KCK17 M12X1.25 6HX STFL BOTT E 374 CH CARBIDE
T351MF120X150R6HX KCK17 M12X1.5 6HX 4F STFL BOTT CH CARB
T351MF140X125R6HX-D4 KCK17 M14X1.25 6HX STFL BOTT E 374 CH CARBIDE
T351MF140X150R6HX KCK17 M14X1.5 6HX 4F STFL BOTT CH CARB
T351MF140X150R6HX-D4 KCK17 M14X1.5 6HX STFL BOTT E 374 CH CARBIDE
T351NC02500-20R3BX KCK17 1/4-20 3BX 4F STFL BOTT CH CARB
T351NC03125-18R3BX KCK17 5/16-18 3BX 4F STFL BOTT CH CARB
T351NC03750-16R3BX KCK17 3/8-16 3BX 4F STFL BOTT CH CARB
T351NC04375-14R3BX KCK17 7/16-14 3BX 4F STFL BOTT CH CARB
T351NC05000-13R3BX KCK17 1/2-13 3BX 4F STFL BOTT CH CARB
T351NC06250-11R3BX KCK17 5/8-11 3BX 5F STFL BOTT CH CARB
T353M050X080R6HX-D1 KCK17 M5X0.8 6HX STFL SBOT C 371 CARBIDE
T353M060X100R6HX-D1 KCK17 M6X1 6HX STFL SBOT C 371 CH CARBIDE
T353M080X125R6HX-D1 KCK17 M8X1.25 6HX STFL SBOT C 371 CH CARBIDE
T353M100X150R6HX-D1 KCK17 M10X1.5 6HX STFL SBOT C 371 CH CARBIDE
T353M120X175R6HX-D6 KCK17 M12X1.75 6HX STFL SBOT C 376 CH CARBIDE
T353M140X200R6HX-D6 KCK17 M14X2 6HX STFL SBOT C 376 CH CARBIDE
